HALDEX-BERG AIR BRAKE

GC3030S4

Brake Chamber

$81.31
Special Order Upon Request
Please Call (866) 439-2329; Email Customer Service or use Chat For details.

Technical Specifications

GC3030S4
21 lb 14 oz
90 DD
3/8-18 NPTF
Combination with Cut-to-Length Rod, without Clevis for Vantraax and Intraax - Size 3030 (T = 0)
64 MM
2.5 IN
8.3 IN
211 MM
259 MM
10.2 IN
Double o-ring center seal and wears rings extend service life and protect against air leakage between chambers
Patented orange alert stoke indicator is visible when brakes are out of alignment
Aluminum center body is durable, lightweight and corrosion resistant
Heat treated power springs for maximum output force and extended life, powder coated for corrosion protection
Epoxy coated clampband and service return spring for additional corrosion resistance
5
229 MM
9 IN
173 MM
6.8 IN
Orange Alert Stroke Indicator
Sizes to fit all drum brake applications.
Self-piloting Dust Shield.
World Class Diaphragm; High quality rubber compound, resistant to heat and cold; Superior flexibility even at -40F.
Double O-ring Centerseal; Two o-rings for positive sealing and plastic bearings for long life.
Superior Power Spring Technology; Advanced powder coating process; Resists corrosion and fatigue.
150 PSI
Y
Gold Seal Spring Brake
BRAKE CHAMBER-GOLD SEAL-3030GC
DDSB drum Gold SS
9.9 IN
5/8-18 UNF
1
(0) DD
9 gauge steel
38.1 MM
1.5 IN
120.7 MM
4.75 IN
5/8-11 UNC
Manufacturer Part Numbers Superseded Parts
HALDEX FRICTION GC3030S4
