HALDEX-BERG AIR BRAKE

GC3030S1

Brake Chamber

$81.74
Special Order Upon Request
Please Call (866) 439-2329; Email Customer Service or use Chat For details.

Technical Specifications

GC3030S1
21 lb 14 oz
90 DD
3/8-18 NPTF
Combination with Clevis & Boot - Size 3030 (S1 = 330 Service)
2.5 IN
64 MM
8.3 IN
211 MM
10.2 IN
259 MM
3 IN
Heat treated power springs for maximum output force and extended life, powder coated for corrosion protection
Patented orange alert stoke indicator is visible when brakes are out of alignment
Double o-ring center seal and wears rings extend service life and protect against air leakage between chambers
Epoxy coated clampband and service return spring for additional corrosion resistance
Aluminum center body is durable, lightweight and corrosion resistant
5
9 IN
229 MM
173 MM
6.8 IN
Orange Alert Stroke Indicator
Double O-ring Centerseal; Two o-rings for positive sealing and plastic bearings for long life.
Self-piloting Dust Shield.
Superior Power Spring Technology; Advanced powder coating process; Resists corrosion and fatigue.
World Class Diaphragm; High quality rubber compound, resistant to heat and cold; Superior flexibility even at -40F.
Sizes to fit all drum brake applications.
150 PSI
Y
Gold Seal Spring Brake
BRAKE CHAMBER-GOLD SEAL-3030GC
DDSB drum Gold SS
1.8 IN
5/8-18 UNF
1
MA15442
(0) DD
9 gauge steel
38.1 MM
1.5 IN
4.75 IN
120.7 MM
5/8-11 UNC
Manufacturer Part Numbers Superseded Parts
HALDEX FRICTION GC3030S1
