GATES RUBBER CO V BELT
$23.74
Special Order Upon Request
Interchangeable With 9420 (2)
Technical Specifications
9420
14 oz
36
2006-05 Isuzu, NPR, Isuzu 4HK1-TC Diesel, Fan & Alt.
Replacement belt for the most demanding engine drives. Due to thermal forces, this variable notched belt actually tightens on the drive as it gets hot. This results in improved belt performance by reducing tension decay and noise.
- Fiber-loaded rubber stock puts more flexibility along the length of the belt, yet gives the belt greater lateral stability in the pulley.
- Thermally active tensile cords for maintenance-free performance when properly installed and tensioned.
- Form ground to ensure precise top width and sidewall dimensional control for proper fit in pulley as well as a smoother, quieter running belt.
- Meets or exceeds SAE J636c specifications
Gates - Driven By Possibility
42.38 IN
1076 MM
1076 MM
V-Belt
High Capacity V-Belt (Standard)
Belt
HC50
.47 IN
12 MM
12 MM
| Manufacturer | Part Numbers | Superseded Parts |
|---|---|---|
| AC DELCO | 9420HD | |
| ADVANCE AUTO PARTS | 9420HD | |
| CAR QUEST | 9420HD | |
| CONTINENTAL-VEYANCE | 17421 | |
| DAYCO CORP | 17420 | |
| GATES RUBBER CO | 9420HD | |
| MACK | 88GB439P421 | 25006980, 25094407, 25622933, 25623002, 88GB177P2, 88GB354P84, 88GB354P91, 88GB439P422 |
| NAPA | 17420, 259420, 259420HD | |
| WORKHORSE PARTS | 9420HD |
Vehicle Fitment
| Make | Model | Years |
|---|---|---|
| CADILLAC | COMMERCIAL CHASSIS | 1981 |
| CADILLAC | DEVILLE | 1981 |
| CADILLAC | ELDORADO | 1981 |
| CADILLAC | FLEETWOOD | 1981 |
| CADILLAC | SEVILLE | 1981 |
| CHEVROLET | C60 | 1979, 1981-1985 |
| CHEVROLET | C70 | 1979-1990 |
| CHEVROLET | W3500 TILTMASTER | 2003-2007 |
| CHEVROLET | W4500 TILTMASTER | 2003-2007 |
| CHEVROLET | W5500 TILTMASTER | 2003-2007 |
| CHEVROLET | W5500HD TILTMASTER | 2004-2007 |
| FORD | F600 | 1992-1994 |
| FORD | F600 LPO | 1993-1994 |
| FORD | F700 | 1992-1996 |
| FORD | F800 | 1993-1996, 1998 |
This list of compatible vehicles and years is accurate, but it may not be complete. There may be additional vehicle applications and years compatible with this part not listed.
